ASUS has listed the ROG Strix X870E-E Gaming WiFi7 Neo on Amazon US. The ATX motherboard is available at $599.99 (Lowest Price on Apr 18, 2026).
Key highlights include the AMD X870E chipset with AM5 socket supporting Ryzen 9000/8000/7000 series, five M.2 slots with PCIe 5.0 support on two CPU-direct slots, WiFi 7 via MediaTek MT7927, dual USB4 40Gbps Type-C rear ports, and 18+2+2 power stages with ROG SupremeFX 7.1 audio.
Pricing & Availability
ASUS ROG Strix X870E-E Gaming WiFi7 Neo – $599.99 – Amazon US↗
ASUS ROG Strix X870E-E Gaming WIFI7 NEO AM5 ATX Motherboard, 18+2+2 Power Stages, DDR5 Slots, 5X M.2 Slots, PCIe 5.0 with Full Support for AMD Ryzen 9000/8000/7000 Series, WiFi 7, Dual USB4 Type-C
by ASUS
Sold by Amazon.com #5 in Computer Motherboards- Ready for Advanced AI PCs: Designed for the future of AI computing, with the power and connectivity needed for demanding AI applications
- AMD AM5 Socket: Ready for AMD Ryzen 9000, 8000 and 7000 series desktop processors
- Exclusive AI Technologies: AI Cache Boost, ASUS AI Advisor, ASUS-exclusive AI Overclocking, AI Cooling II, AI Networking II
Quick Links
CPU & Chipset
The ROG Strix X870E-E Gaming WiFi7 Neo uses the AMD AM5 socket paired with the AMD X870E chipset. Compatible processors include:
- AMD Ryzen 9000 Series desktop processors
- AMD Ryzen 8000 Series desktop processors
- AMD Ryzen 7000 Series desktop processors
The board ships with a 64MB (512Mb) Flash ROM UEFI AMI BIOS for broad AM5 CPU compatibility, along with a redesigned BIOS interface.
Memory
- Slots: 4× DIMM, max. 256GB DDR5
- Ryzen 9000 Series: Up to 8600+ MT/s (OC) / 8200+ MT/s (EXPO/AEMP)
- Ryzen 8000 Series: Up to 9600+ MT/s (OC) / 9000+ MT/s (EXPO/AEMP)
- Ryzen 7000 Series: Up to 8000+ MT/s (OC) / 8000+ MT/s (EXPO/AEMP)
- Architecture: Dual-channel
- ECC: Supports ECC and Non-ECC Un-buffered DIMM (Non-ECC DDR5 supports On-Die ECC)
- Profiles: AMD EXPO, ASUS AEMP (Enhanced Memory Profile)
- Extras: NitroPath DRAM Technology, DIMM Fit, DIMM Fit Pro
Expansion Slots
With Ryzen 9000 & 7000 Series:
- 1× PCIe 5.0 x16 slot (x16 mode)
With Ryzen 8700 / 8600 / 8400 Series:
- 1× PCIe 4.0 x16 slot (x8 mode)
With Ryzen 8500 / 8300 Series:
- 1× PCIe 4.0 x16 slot (x4 mode)
AMD X870E Chipset:
- 1× PCIe 4.0 x16 slot (x4 mode)
The PCIe 5.0 x16 slot features SafeSlot reinforcement and Q-Release for tool-free GPU removal.
Storage
All five M.2 slots use Key M type and feature Q-Release, Q-Latch, and Q-Slide for EZ installation.
With Ryzen 9000 & 7000 Series:
- M.2_1: 2242/2260/2280, PCIe 5.0 x4
- M.2_2: 2242/2260/2280, PCIe 5.0 x4 (shares bandwidth with rear USB4 Type-C ports — both run at x2 when M.2_2 is occupied; switchable to x4 in BIOS, which disables USB4 ports)
With Ryzen 8700 / 8600 / 8400 Series:
- M.2_1: 2242/2260/2280, PCIe 4.0 x4
- M.2_2: 2242/2260/2280, PCIe 4.0 x4
AMD X870E Chipset (all CPU types):
- M.2_3: 2280, PCIe 4.0 x4 (shares bandwidth with PCIEX16(G4); installing a drive disables that slot)
- M.2_4: 2280, PCIe 4.0 x4
- M.2_5: 2280, PCIe 4.0 x4
SATA:
- 4× SATA 6Gb/s ports
RAID: AMD RAIDXpert2 — RAID 0/1/5/10 (Ryzen 9000/8000/7000 Series)
Networking
- Ethernet: 1× Realtek 5GbE with ASUS LANGuard
- WiFi: Wi-Fi 7 (MediaTek MT7927), 2×2, 802.11be, 2.4/5/6 GHz, 320 MHz bandwidth
- Bluetooth: Bluetooth with LE Audio support (version varies by module revision)
- Antenna: ASUS WiFi Q-Antenna (included)
USB — Rear Panel (13 ports total)
- 2× USB4 40Gbps (USB Type-C with DisplayPort Alt mode)
- 1× USB 10Gbps Type-C (up to 30W PD/PPS Fast-charge)
- 9× USB 10Gbps Type-A
- 1× USB 10Gbps Type-C
USB — Front Panel Headers (12 ports total)
- 2× USB 20Gbps connector (USB Type-C)
- 2× USB 5Gbps headers (supports 4 additional USB 5Gbps ports)
- 3× USB 2.0 headers (supports 6 additional USB 2.0 ports)
Audio
The ROG Strix X870E-E Gaming WiFi7 Neo uses the ROG SupremeFX 7.1 Surround Sound codec — Realtek ALC4080 — with the following specs:
- SNR: 120 dB stereo playback output / 110 dB recording input
- Playback: Up to 32-bit/384 kHz (front panel)
- Amplifier: Savitech SV3H712
- Wireless audio: LHDC codec support — up to 400 kbps, 24-bit/192 kHz (requires LHDC-compatible headset)
- Output: Gold-plated audio jacks, rear optical S/PDIF out
- Features: Audio Shielding, premium audio capacitors, audio cover, impedance sense for front and rear headphone outputs, jack-detection, multi-streaming, front panel MIC jack-retasking
Back Panel I/O
- 2× USB4 40Gbps Type-C (DP Alt mode)
- 1× USB 10Gbps Type-C (30W PD/PPS Fast-charge)
- 9× USB 10Gbps Type-A
- 1× USB 10Gbps Type-C
- 1× HDMI 2.1 (4K@60Hz)
- 1× Realtek 5GbE Ethernet
- 1× Wi-Fi module port (Q-Antenna connector)
- 2× Audio jacks
- 1× Optical S/PDIF out
- 1× BIOS FlashBack button
- 1× Clear CMOS button
Display output note: USB4 Type-C ports support DisplayPort 1.4a output (max 4K@60Hz). During OS installation, connect monitor to the HDMI port or a discrete GPU.
Internal Connectors
Fan & Cooling:
- 1× 4-pin CPU Fan header
- 1× 4-pin CPU OPT Fan header
- 1× 4-pin AIO Pump header
- 5× 4-pin Chassis Fan headers
- 1× AIO Q-Connector
Power:
- 1× 24-pin Main Power connector
- 2× 8-pin +12V CPU Power connectors
Storage:
- 5× M.2 slots (Key M)
- 4× SATA 6Gb/s ports
Miscellaneous:
- 3× Addressable RGB Gen 2 headers
- 1× Alteration PCIe mode switch
- 1× Chassis Intrusion header
- 1× CPU Overvoltage jumper
- 1× Front Panel Audio header (F_AUDIO)
- 1× Start button
- 1× 10-1 pin Front Panel System header
- 1× Thermal Sensor header
AI & Overclocking Features
- AI Cache Boost — optimises CPU cache and memory pathways for AI workloads
- ASUS AI Advisor — system tuning guidance
- AI Overclocking — ASUS-exclusive automated overclocking via BIOS and Armoury Crate
- AI Cooling II — AI-based fan curve management
- AI Networking II — network traffic prioritisation
- Dynamic OC Switcher — switches OC profiles based on workload
- Core Flex — per-core frequency tuning
- Asynchronous Clock — independent control of CPU and memory clocks
- PBO Enhancement — AMD Precision Boost Overdrive tuning support
- Extreme Engine Digi+ — digital power delivery with 5K black metallic capacitors
- ProCool II — reinforced power connector design
EZ DIY & Build Features
- BIOS FlashBack — update BIOS without CPU/RAM installed
- Q-Code — two-digit POST code display
- Q-Dashboard — onboard header identification
- Q-LED — CPU (red), DRAM (yellow), VGA (white), Boot Device (yellow-green)
- SafeSlot — reinforced PCIe x16 slot
- SafeDIMM — reinforced DIMM slots
- M.2 Q-Release / Q-Latch / Q-Slide — tool-free M.2 installation
- PCIe Slot Q-Release — one-press GPU removal
- Q-Antenna — snap-fit WiFi antenna connector
- Dual DIMM clips — single-side DIMM latch
- Pre-mounted I/O shield
- M.2 heatsinks + backplate
- VRM heatsink
- Aura Sync — 3× ARGB Gen 2 headers
BIOS
- Capacity: 64MB (512Mb) Flash ROM, UEFI AMI BIOS
- Features: AI Overclocking Guide, AI Cache Boost, CrashFree BIOS 3, EZ Flash 3, UEFI BIOS EZ Mode, MyHotkey, FlexKey, Integrated WiFi Driver Support
- Manageability: WOL by PME, PXE
Software
ROG Exclusive:
- ROG CPU-Z
- Dolby Atmos
- Polymo Lighting
ASUS Armoury Crate:
- Aura Creator / Aura Sync
- Fan Xpert 4 (with AI Cooling II)
- GameFirst
- WiFi Q-Antenna
- MLO Wizard
ASUS DriverHub & Utilities:
- ASUS MB Manager
- ASUS AI Advisor
- AIDA64 Extreme (60-day free trial)
- HWiNFO
- ASUS GlideX
- USB Wattage Watcher
- TurboV Core
- Norton 360 for Gamers (60-day free trial)
- WinRAR (40-day free trial)
- Adobe Creative Cloud (free trial)
ASUS ROG Strix X870E-E Gaming WiFi7 Neo Specifications / Technical Details
- Model: ROG Strix X870E-E Gaming WiFi7 Neo
- Socket: AMD AM5
- Chipset: AMD X870E
- CPU Support: AMD Ryzen 9000 / 8000 / 7000 Series
- Form Factor: ATX (12 × 9.6 inch / 30.5 × 24.4 cm)
- Memory: 4× DIMM, DDR5, max 256GB, dual-channel
- Memory Speed: Up to 9600+ MT/s (OC, Ryzen 8000 Series)
- Memory Profiles: AMD EXPO, ASUS AEMP, DIMM Fit, DIMM Fit Pro, NitroPath
- PCIe (CPU): 1× PCIe 5.0 x16 (Ryzen 9000/7000) or PCIe 4.0 x16 (Ryzen 8000)
- PCIe (Chipset): 1× PCIe 4.0 x16 (x4 mode)
- M.2 Slots: 5× (2× PCIe 5.0 x4 CPU-direct + 3× PCIe 4.0 x4 chipset)
- SATA: 4× SATA 6Gb/s
- RAID: RAID 0/1/5/10 (AMD RAIDXpert2)
- Ethernet: 1× Realtek 5GbE
- WiFi: Wi-Fi 7 (MediaTek MT7927), 802.11be, 2.4/5/6 GHz, 320 MHz
- Bluetooth: Yes (LE Audio)
- Rear USB: 2× USB4 40Gbps Type-C, 9× USB 10Gbps Type-A, 2× USB 10Gbps Type-C (one with 30W PD)
- Front USB: 2× USB 20Gbps Type-C, 4× USB 5Gbps, 6× USB 2.0
- Display Out (Rear): 1× HDMI 2.1, 2× USB4 Type-C (DP 1.4a Alt mode)
- Audio: ROG SupremeFX 7.1, ALC4080, 120dB SNR, 32-bit/384 kHz, optical S/PDIF out
- Fan Headers: 1× CPU, 1× CPU OPT, 1× AIO Pump, 5× Chassis
- RGB: 3× ARGB Gen 2 headers, Aura Sync
- Power Stages: 18+2+2
- Power Connectors: 1× 24-pin, 2× 8-pin CPU
- BIOS: 64MB Flash ROM, UEFI AMI, BIOS FlashBack, CrashFree BIOS 3
- OS Support: Windows 11
Related Motherboards to check out on Amazon US
What’s in the Box
- ASUS ROG Strix X870E-E Gaming WiFi7 Neo Motherboard
- 2× SATA 6Gb/s cables
- 1× ASUS WiFi Q-Antenna
- 1× DDR5 fan holder
- 1× ROG assistant fan (60mm)
- 1× Screw package for cooling kit
- 1× Cable ties package
- 1× M.2 Q-Latch package
- 1× M.2 Q-Slide package
- 5× M.2 rubber packages
- 1× ROG key chain
- 1× ROG Strix stickers
- 1× ROG Strix thank you card
- 1× Quick start guide
Note: Specifications listed above are based on available information and may not be 100% accurate. Please visit the official ASUS website or Amazon product page to verify complete and up-to-date specifications before making a purchase decision.
